Videojet 3640 Laser Marking Systems

Marking speed

Up to 2, 100 characters/sec.( 1)

Line speed

Up to 15m/sec. (49ft/sec.)(1)

Marking window

Approx. 30.8 x 38.2mm2

to 601.0 x 439.8mm2

Wavelengths

10.6 μm,10.2 μm and 9.3 μm

Marking formats

Standard industrial fonts (Type 1 Windows® TrueType®) and Single line fonts

Machine readable codes (OCR, 2D-matrix, etc.)

Bar codes: BC25, BC25i, BC39, BC128, GS1- 128, EAN13, UPC_A, RSS14,

RSS14 Truncated, RSS14 Stacked, RSS14 Stacked Omnidirectional, RSS Limited,

RSS Expanded, etc.

Graphics, logos, symbols, etc.

Linear, circular, angular, reverse, rotate

Sequential and batch numbering

Automatic date, layer and time coding; real-time clock

Dot mode enables marking 2D codes faster than traditional grid mode

Laser tube

Sealed CO2

laser, power class 60-Watt

Beam deflection

Steered beam with digital high-speed galvanometer scanners

Focusing

Focal lengths: 64/ 95/ 127/ 190/ 254 mm (2.5/ 3.75/ 5.0/ 7.5/ 10.0 inches);

63.5/ 85/ 100/ 150/ 200/ 300/ 351/ 400 mm (2.50/ 3.35/ 3.94/ 5.9/ 7.87/ 11.8/

13.8/ 15.75 inches); 100/ 150/ 200/ 300/ 351 mm (3.9/ 5.9/ 7.9/ 11.8/ 13.8 inches);

400/ 500/ 600 mm ( 15.75/ 19.68/ 23.62 inches)

Multiple operator interface options

Handheld controller

PC software

TCS Touch Control Software

CLARiTYTM Laser Controller

Smart Graph Com

Language capabilities(2)

Arabic, Bulgarian, Czech, Danish, English, German, Greek, Finnish, French,

Hebrew,

Hungarian, Italian, Japanese, Korean, Dutch, Norwegian, Polish, Portuguese,

Romanian,

Russian, Serbian, Simplified Chinese, Slovak, Spanish, Swedish, Thai, Traditional

Chinese,

Turkish, Vietnamese; interface dependent. Additional languages available with

Smart Graph software.

Communication

Ethernet, TCP/IP and RS232 optional

Inputs for encoders and product detector triggers

16 inputs / 1 1 outputs for start/stop signals, machine/operator interlocks, alarm outputs;

in addition to the safety circuits

Customer-specific solutions available

Integration

Direct integration into complex production lines via scripting interface

Flexible beam delivery options (beam extension unit/ beam turning unit)

Detachable umbilical for simple integration; available in 3 lengths

Electrical requirements

100-240 VAC (autorange), ~50/60Hz, 1PH, 1. 15kW

Cooling system

Air cooled

Environment

Temperature 40- 105° F (5-40° C)

Humidity 10%-90%, non-condensing

Sealing and safety standards

Supply Unit: IP54, optional IP65

Marking Unit: IP54, optional IP65

Optional safety module provides Performance Level d (PFL-d) in accordance

to EN 13849- 1

IEC/EN 60825- 1:2014

Approximate weight

Supply unit: IP54/IP65 25.4lbs. ( 11.5kg)

Marking unit: IP54 58.4 lbs. (26.5kg); IP65 59.5lbs. (27kg)

Applicable certifications

CE, TÜV/NRTL, FCC

Compliance (no certification required): ROHS, CDRH/FDA

Marking unit dimensions – IP54 with SHC60c marking head
